SiP(System-in-Package) / 3D Package Turnkey Service
SiP Turnkey Design Solution
SiP Turnkey
Design Solution
SiP Package Type
SiP Package Type
- The System-in-Package (SiP) implements 2.5D & 3D technology in integrated modules with several chip packages arranged side by side or stacked, achieving functional systems or subsystems at the package level.
- SiP has primarily been used in mobile, HPC, automotive, and AI applications, … , etc. Based on the customer′s requirement, PGC could offer suitable SiP selections to ensure reducing costs and time to market.
Chip-Package- System Vertical Align
Chip-Package-
System Vertical Align
SiP Design
SiP Design
KGD Vendor Management
- Long term partnership with standalone memory suppliers.
- Logistic management and inventory control
- MOQ management
- Quality management
- Consign
SiP Design Platform Service
SiP Design
Platform Service
Electrical Simulation
Thermal Simulation
MCM QFP Stacked Die
SiP Side by Side
SiP Stacked BGA
SiP Success Story
Over 1000 successful ASIC design projects tape out at TSMC(1991 – 2024)
- Package: Flip Chip BGA 2601L
- Layer: 4+2+4 Layers
- Ball Diameter:0.6 (mm)
- Ball Pitch:1.0 (mm)
- U1:SoC
- U2:SoC
- Application: Super computer
- Package Type: STK LFBGA-100
- Layer: 4 layers
- Ball Pitch: 0.8 mm
- U1: ASIC
- U2: Flash
- Application: GPS
- Package Type: QFN-64L (Green)
- Pin Pitch: 0.5 mm
- U1: Flash
- U2: TTBD ASIC
- Application: GPS
- Package: SBS LFBGA 225L
- Layer: 4 Layers
- Ball Diameter:0.4mm
- Ball Pitch:0.8 mm
- U1:RF
- U2: Baseband ASIC
- Application: Wireless (Zigbee)
- Package: SBS LFBGA 112L
- Layer: 4 Layers
- Ball Diameter: 0.4(mm)
- Ball Pitch: 0.8(mm)
- U1: ASIC
- U2: SRAM 1Mbits(128K x 8bits)
- U3: Flash 4Mbits(512K x 8bits)
- Application: PLC
- Process: TSMC 90nm 1P10M Flip Chip (1150 balls)
- Frequency: 500Mhz
- IP : LVDS, DDRII PHY
- Application : CPU
- Process: TSMC 0.13um 1P8M Flip Chip
- IP : LVDS, USB2.0, PCIe, SATA2
- Application : I/O HUB
2.5D and 3D IC Packaging
3D Substrate Layout
3D Electrical Extraction
